HighCom STRIKER RCHMC Rifle Combat Helmet Level III+ (Mid Cut)
If you live in the USA your item will be shipped directly from the USA to you. (Lead times may apply)
If you live outside the USA, after Purchasing, compliance for you will need to be carried out, this will take approximatly 45 days (Could take longer). Please only purchase if the job/role you are carrying out requires you to use this item. Compliance comes from the USA.
If you are a Public Service, Government Agency looking to procure these please contact the UK Exclusive Distributor www.cldistribution.co.uk
ABOUT
The Striker RCHMC™ (Rifle Combat Helmet Mid Cut) Level III+ helmet exceeds the U.S. military specifications for ballistic threats, fragmentation, and blunt impact. A true rifle rated helmet, the Striker RCHMC is capable of defeating rifle special threats including 7.62 x 51mm (M80), 7.62 x 39mm (M43 MSC), 5.56 x 45mm (M193 FMJ), as well as MIL-STD frag protection beyond any protective helmet currently in theatre.
SPECIFICATIONS
- Protection: Level III+ rifle rated ballistic helmet including frag protection
- Rifle Special Threat Tested: According to U.S. DOD proprietary test requirements
- MIL-STD-662F: This product has been independently tested by an NVLAP accredited NIJ approved laboratory against frag resistance as specified under MIL-STD-662F
- XTclave: Made in XTclave™ Ultra-high Pressure Consolidation. XTclave™ is a composite curing and consolidation technology that makes it possible to manufacture lighter, stronger and stiffer composite articles
- Materials: 100% UHMWPE DSM Dyneema®
- Head Protection: Front, back, crown, and side of the head
- Weight: 11 kg/m²areal density, 1.07 kg total weight (raw shell weight only, based on size large)
- Thinness: 0.43” or 11mm
- Retention: Helmet includes HighCom’s 4pt Retention Harness, multiple options available
- Suspension: Comes standard with D3O® TRUST Stealth™ 7-pad system, multiple options available
- Sizing: Circumference is measured around the head, similar to hat sizing. All sizes are measured in inches. If a measurement falls on a dividing line between sizes, select the larger of the two sizes to ensure maximum ballistic protection
- Warranty: 5 years on all ballistic material excluding exterior cover, 1 year on exterior cover material and workmanship
LEVEL III RIFLE THREATS
PROJECTILE | GR | VEL FT/S | VEL M/S | (+/- FT/S) | (+/- M/S) |
---|---|---|---|---|---|
7.62 x 51mm FMJ, Steel Jacketed Bullets (M80) | 147 | 2750 | 838 | (+/- 50) | (+/- 50) |
7.62 x 39mm (M43 MSC PS) | 123 | 2379 | 725 | (+/- 50) | (+/- 15) |
5.56 x 45mm M193 FMJ | 55 | 3250 | 991 | (+/- 50) | (+/- 15) |
9mm Full Metal Jacketed Round Nose (FMJ RN) | 124 | 1400 | 427 | (+/- 30) | (+/- 9) |
.44 Magnum Semi Jacketed Hollow Point (SJHP) | 240 | 1400 | 427 | (+/- 30) | (+/- 9) |
MIL-STD-662F FRAG THREATS
PROJECTILE | GR | VEL FT/S | VEL M/S | V50 FT/S | V50 M/S |
---|---|---|---|---|---|
US MIL-STD Frag 2 gr. RCC | 2 | 4200 | 1280 | >5391 | 1643 |
US MIL-STD Frag 4 gr. RCC | 4 | 3475 | 1059 | >5163 | 1574 |
US MIL-STD Frag 16 gr. RCC | 16 | 2475 | 754 | 4074 | 1242 |
US MIL-STD Frag 64 gr. RCC | 64 | 1750 | 533 | 2852 | 869 |
US MIL-STD Frag 17 gr. FSP | 17 | 2200 | 671 | 4187 | 1276 |
US MIL-STD Frag 44 gr. FSP | 44 | 1750 | 533 | 3177 | 969 |
Small - 21.1” to 21.9”
Medium - 21.9” to 22.7”
Large - 22.7” to 24”
Extra Large - 24” to 26”
If you live in the USA your item will be shipped directly from the USA to you. (Lead times may apply)
If you live outside the USA, after Purchasing, compliance for you will need to be carried out, this will take approximatly 45 days (Could take longer). Please only purchase if the job/role you are carrying out requires you to use this item. Compliance comes from the USA.
If you are a Public Service, Government Agency looking to procure these please contact the UK Exclusive Distributor www.cldistribution.co.uk
